Metal seals

  • UHV applications up to 10-11 mbar
  • pressurized applications up to 20 bar
  • cryogenics applications down to -270°C
  • maximum temperature up to 150°C
  • flange seals reusable up to 10 times
  • radiation tolerant and nuclear applications
  • cleanroom compatible

KF Aluminum Edge Seal - Outer Center Ring

P/N DN A C1 J Quantity
34.016001.142.116-az 10/16 30 20 23 Add
34.025001.142.125-az 20/25 40 32 33 Add
34.040001.142.140-az 32/40 55 45 48 Add
34.050001.142.150-az 50 75 65 68 Add
34.063001.142.163-az 63 87 77 80 Add

Please, enter a numeric value

KF Aluminum Edge Seal - Inner Center Ring

P/N DN C C1 J Quantity
34.016001.142.116-iz 10/16 15 17 21 Add
34.025001.142.125-iz 20/25 24 26 30 Add
34.040001.142.140-iz 32/40 39 41 47 Add
34.050001.142.150-iz 50 50 52 59 Add
34.063001.142.163-iz 63 68 70 77 Add

Please, enter a numeric value

KF Aluminum Edge Seal - One Side Outer Center Ring

P/N DN A C1 J Quantity
34.016001.142.116az1 10/16 30 20 23 Add
34.025001.142.125az1 20/25 40 32 33 Add
34.040001.142.140az1 32/40 55 45 48 Add
34.050001.142.150az1 50 75 65 68 Add
34.063001.142.163az1 63 87 77 80 Add

Please, enter a numeric value

KF Aluminum Edge Seal - One Side Inner Center Ring

P/N DN C C1 J Quantity
34.016001.142.116iz1 10/16 15 17 21 Add
34.025001.142.125iz1 20/25 24 26 30 Add
34.040001.142.140iz1 32/40 39 41 47 Add
34.050001.142.150iz1 50 50 52 59 Add
34.063001.142.163iz1 63 68 70 77 Add

Please, enter a numeric value

ALUMINUM SEALS FOR ISO "TAPERED" FLANGES

ALUMINUM SEALS FOR ISO "TAPERED" FLANGES







Only used with EVAC flanges.

Dimensions of the 4 series of Aluminum seals

DN A J (4 mm) J (2 mm) B K
80 114 107 108 83 90
100 134 127 128 102 109
125 161 154 155 127 134
160 190 183 184 153 160
200 252 245 246 213 220
250 301 294 295 261 268



Aluminum Seal (4mm) - One Side Outer Center Ring





Only for chain clamp BX type

P/N DN Quantity
34.080001.272.108az1 80 Add
34.100001.272.110az1 100 Add
34.125001.272.112az1 125 Add
34.160001.272.116az1 160 Add
34.200001.272.120az1 200 Add
34.250001.272.125az1 250 Add

Please, enter a numeric value

Aluminum Seal (4mm) - Inner Center Ring





Can also be used with ISO-F flanges

P/N DN Quantity
34.080001.342.108 80 Add
34.100001.342.110 100 Add
34.125001.342.112 125 Add
34.160001.342.116 160 Add
34.200001.342.120 200 Add
34.250001.342.125 250 Add

Please, enter a numeric value

Aluminum Seal (4mm) - Outer Center Ring





Only for chain clamps BX type

P/N DN Quantity
34.080001.272.108 80 Add
34.100001.272.110 100 Add
34.125001.272.112 125 Add
34.160001.272.116 160 Add
34.200001.272.120 200 Add
34.250001.272.125 250 Add

Please, enter a numeric value

Aluminum Seal (2mm) - Outer Center Ring

P/N DN Quantity
34.080001.271.108 80 Add
34.100001.271.110 100 Add
34.125001.271.112 125 Add
34.160001.271.116 160 Add
34.200001.271.120 200 Add
34.250001.271.125 250 Add

Please, enter a numeric value
